Z-Arm S922 Core Facts
±0.1mm
Repeatability
5Kg
Max payload
922mm
Reach
Φ150mm
Footprint
* Drawing
Product Features
Easy Programming
HHow to easily program a robot even without coding skills and robotics knowledge? Don't worry, HITBOT Z-Arm S922 is quite clever at learning. Simply drag and drop its arm to the desired position, or use graphical blocks in the APP, HITBOT Z-Arm S922 will quickly remember and follow the exact path. The whole intuitive programming process only takes several minutes.
Quick Delopyment
Compact and light, HITBOT Z-Arm S922C has its reducer, motor, encoder, and drive controller integrated as a whole, which greatly improves the convenience of installation and redeployment.
Flexible Application
Designed to handle payloads up to 5KG, HITBOT Z-Arm S922 can be trusted by different industries, such as automotive, electronics, food and beverage, healthcare and lab research, for various applications, like assembly, pick and place, screwdriving, dispensing, and gluing. As long as you have demands, HITBOT Z-Arm S922 can help you achieve in action.
Trusted Safety
HITBOT Z-Arm S922C is human-friendly. Even without fences, it can be deployed to work alongside people as it supports collision detection control. Operators can move freely around the robot without concerns for their safety or impacting production. HITBOT Z-Arm S922C helps you to create quite a safe working environment.
| Model | Z-arm S922 | |
| Number of axis | 6 | |
| Maximum payload | 5KG | |
| Weight | 18.5KG | |
| Maximum reach | 922mm | |
| J1 rotation (1-axis) | ±175° | |
| J2 rotation (2-axis) | +85°,-265° | |
| J3 rotation (3-axis) | ±160° | |
| J4 rotation (4-axis) | +85°,-265° | |
| J5 rotation (5-axis) | ±175° | |
| J6 rotation (6-axis) | ±175° | |
| Speed | ±180°/s | |
| Repeatability | ±0.1mm | |
| Footprint | ±150mm | |
| IP classification | IP54 | |
| Noise | Less than 60db | |
| End DI/DO ports | Digital input: 2 | Digital output: 2 |
| End AI/AO ports | Analog input: 1 | Analog output: 1 |
| Control box DI/DO ports | Digital input: 16 | Digital output: 16 |
| Control box AI/AO ports | Analog input: 2 | Analog output: 2 |
| I/O power supply | 24V/2A | |
| Power intput | 220V/50Hz | |
| Operating temperature | 0-45℃ | |
| Humidity | 90%RH (non-condensing) | |
| Teach pendant | Drag to Teach / Jog mode | |
| Communication | TCP | |
| Collision detection | Supported | |
| Collaboration | Collision detection (with custom collision level supported) | |
